ST1-021057DF-01
|
Mechanical Specifications(技术要求）
|
|
|
Full Stroke(满冲程)
|
1.00mm
|
|
Rated Stroke(额定程)
|
0.65mm
|
|
Spring Force(额定弹力）
|
11gf±20%
|
| Materials(plated)(材质与镀层) | |
|
Barrel(针管)
|
Phosphor Bronze Gold plated
|
|
Plunger Top(针头Top)
|
Hardened BeCu Gold plated
|
|
Plunger Bottom(针头Bottom)
|
Hardened BeCu Gold plated
|
|
Spring(弹弓)
|
Music wire Gold plated
|
| Electrical Specifications(电子参数) | |
|
Rated Current(额定电流)
|
1.0A
|
|
Contact Resistance(接触电阻)
|
100 mohm Max
|
|
Bandwidth(频宽)
|
|
| head shape can be customized（头型可定制 ） |
|
|
